Product Detail
Product Specs
| Model | Mag. | WD (mm) | NA | Co-axial Lighting | Mount | |
|---|---|---|---|---|---|---|
| VS-TCH05-65 | 0.5x | 75.3 | 0.027 | – | C-Mount | |
| VS-TCH08-65 | 0.8x | 70.3 | 0.042 | – | ||
| VS-TCH1-65 | 1.0x | 68.8 | 0.050 | – | ||
| VS-TCH1-50 | 1.0x | 53.3 | 0.050 | – | ||
| VS-TCH1.5-65 | 1.5x | 65.0 | 0.064 | – | ||
| VS-TCH2-65 | 2.0x | 65.0 | 0.074 | – | ||
| VS-TCH3-60 | 3.0x | 59.8 | 0.073 | – | ||
| VS-TCH4-65 | 4.0x | 65.0 | 0.112 | – | ||
| VS-TCH6-65 | 6.0x | 65.8 | 0.111 | – | ||
| VS-TCH05-65CO | 0.5x | 75.3 | 0.027 | ○ | ||
| VS-TCH08-65CO | 0.8x | 70.3 | 0.042 | ○ | ||
| VS-TCH1-50CO | 1.0x | 53.3 | 0.050 | ○ | ||
| VS-TCH1-65CO | 1.0x | 68.8 | 0.050 | ○ | ||
| VS-TCH1.5-65CO | 1.5x | 65.0 | 0.064 | ○ | ||
| VS-TCH2-65CO | 2.0x | 65.0 | 0.074 | ○ | ||
| VS-TCH3-60CO | 3.0x | 59.8 | 0.073 | ○ | ||
| VS-TCH4-65CO | 4.0x | 65.0 | 0.112 | ○ | ||
| VS-TCH6-65CO | 6.0x | 65.8 | 0.111 | ○ | ||
| VS-TCH05-110 | 0.5x | 110.8 | 0.026 | – | ||
| VS-TCH08-110 | 0.8x | 110.7 | 0.036 | – | ||
| VS-TCH1-110 | 1.0x | 110.3 | 0.048 | – | ||
| VS-TCH1.5-110 | 1.5x | 110.8 | 0.063 | – | ||
| VS-TCH2-110 | 2.0x | 110.8 | 0.074 | – | ||
| VS-TCH3-100 | 3.0x | 103.1 | 0.072 | – | ||
| VS-TCH4-110 | 4.0x | 110.8 | 0.090 | – | ||
| VS-TCH6-110 | 6.0x | 110.9 | 0.076 | – | ||
| VS-TCH05-110CO | 0.5x | 110.8 | 0.026 | ○ | ||
| VS-TCH08-110CO | 0.8x | 110.7 | 0.036 | ○ | ||
| VS-TCH1-110CO | 1.0x | 110.3 | 0.048 | ○ | ||
| VS-TCH1.5-110CO | 1.5x | 110.8 | 0.063 | ○ | ||
| VS-TCH2-110CO | 2.0x | 110.8 | 0.074 | ○ | ||
| VS-TCH3-100CO | 3.0x | 103.1 | 0.072 | ○ | ||
| VS-TCH4-110CO | 4.0x | 110.8 | 0.090 | ○ | ||
| VS-TCH6-110CO | 6.0x | 110.9 | 0.076 | ○ |
Low distortion
High contrast in entire Filed of View
Lens Resolution, NA and Depth of Field (DOF)
[Testing Environment]
Camera : STC-A152A
Lens: NA High VS-TC M022-150/S (Open) NA Low VS-TCM022-150/S (Close)
Lighting: Chart: UEB-70W50 Dice: UNSL-73W100
