Genie Nano C1450 is a Teledyne Dalsa industrial camera that uses Sony’s IMX273 color chip. Teledyne Dalsa’s unique Burst Acquisition technology and TurboDriver features enable it to achieve an acquisition rate of 161fps at VGA resolution while ensuring high-quality image quality. All Genie cameras are supported by Teledyne Dalsa Sapera software.
Characteristic highlights:
Outstanding cost-effectiveness
Ultra small exterior design
The GigE interface currently dominant in the market
Easy support for 100 meter data cable transmission
Flexible I/O settings, ultra-low latency, and more precise timing
application area
Industrial testing: used for detecting surface defects, size measurement, shape detection, etc. of products, such as in industries such as electronic manufacturing, automotive manufacturing, food packaging, etc.
Machine vision: used in automated production lines for object recognition, positioning, tracking, etc., to achieve automated production and quality control.
Scientific research: used in astronomy, biology, medicine, and other fields for image acquisition and analysis, helping scientists conduct research and experiments.
Medical imaging: In medical imaging equipment such as X-rays, CT, MRI, etc., it is used to obtain images of the interior of the human body to assist doctors in diagnosis.
Security monitoring: used to monitor public places, roads, buildings, etc., to achieve security prevention and monitoring management.
| Product ID | G3-GM10-C1450 |
| Resolving power | 1456 x 1088 |
| Frame speed | 75fps, up to 161fps with TurboDriver enabled |
| Black and white/color | Color industrial camera |
| Photosensitive chip | Sony IMX273 |
| chip type | Global Shutter CMOS |
| Pixel size | 3.45µm x3.45µm |
| Chip size | 1/2.9″ |
| Pixel depth | 8/12 bits |
| Video output format | Bayer 8-bit、Bayer 12-bit、RGBA 32-bit、RGB 24-bit、Yuv422 16-bit、Mono 8-bit |
| Exposure control | Set exposure time through camera control software or API programming External trigger signal pulse width controls exposure duration |
| Number of I/O | 4 GPIO ( 2 Inputs / 2 Outputs ) |
| Synchronization method | Free running, free collection method
External trigger signal hard triggering method Through Ethernet soft triggering method |
| Lens interface | C or CS |
| data interface | GigE |
| External dimensions | 21 mm x 29 mm x 44 mm (including C interface) |
| weight | 47g |
| working temperature | -20℃~+65℃ |
| Power requirements | +10V~+36V (± 10%) or PoE |
| Typical power consumption | 3.8W ~ 4.9W |
| software kit | Sapera LT 8.00 or above version |
| Compliant with standards | CE，FCC，RoHS |
| Place of Origin | Import |
| brand | Teledyne Dalsa |
